Response DT8

ProAc invests a great deal of time researching the choice of diaphragm material for their drive units.

Some materials excel at certain frequencies and therefore it is logical to use more than one type of drive unit material to cover all frequencies.

The Response DT8, incorporates these design parameters for the first time in a ProAc two-way design. Utilising 2 x 6.5-inch drivers, the pulp mica cone unit delivers exceptional bass performance in a ported cabinet with the bass loaded via side vents. The polypropylene unit gives a smooth, detailed and uncoloured midrange. Both drivers work in tandem, resulting in a well extended low frequency response and ProAc’s natural sounding midrange with pinpoint imagery.

These frequency ranges are then cleverly overlapped by a Stewart Tyler designed crossover, which seamlessly integrates ProAc’s proven 1-inch soft dome tweeter. The tweeter is mounted in an offset position between the two bass drivers.

The Response DT8 takes its place in the ProAc range as our entry level floor-standing design.

We believe that this innovative loudspeaker will create interest in the mixing and matching of drive unit materials to effectively cover all types of music.



Featured veneer: Oak

Specification

Nominal Impedance

4 ohms

Recommended Amplifiers

20 to 180 watts

Frequency Response

28Hz-30kHz

Sensitivity

90 dB linear for 1 watt at 1 metre

Bass /midrange drivers

2x 6.5” bass/mid units. One driver with Pagina Mica cone and open weave dust cap and one driver with polypropylene cone with soft polypropylene dust cap. Both units working in tandem.

Tweeter

ProAc 1” silk dome tweeter

Crossover

Specially designed crossover to accommodate two different types of bass/mid cones. Glass fibre board with finest components using multistrand copper wire designed for use with both Bi-amping and Bi-wiring.

Height (Cabinet)

978mm on spikes(38.5”)

Width (Cabinet)

193mm (7.6”)

Depth (Cabinet)

229mm (9”)

Weight

26kg each (55lb)

Mode

Stand mounting

Grille

Acoustically transparent crimplene

Standard Finishes

Black Ash, Mahogany, Cherry, Oak, Silk White and Walnut

Premium Finishes

Rosewood, Ebony. *Premium Finishes to order at extra cost*

Related Products

The ProAc Response D30S is available with either a dome or ribbon tweeter, known as the D30DS and D30RS respectively.

"The thought of achieving a loudspeaker that can fool you into believing you are listening to the real thing is the first thing in a designer's mind."

Stewart Tyler
